Avalue EMO-Q670: ATX Industrial Motherboard for High-Performance Workstations

Overview: EMO-Q670

The Avalue EMO-Q670 is a full-size ATX (305×244mm) industrial motherboard based on the Intel Q670 chipset, supporting 12th and 13th Generation Intel Core, Core i9, Xeon W, and Pentium/Celeron processors in an LGA1700 socket. It is designed for high-performance SCADA servers, machine vision workstations, and AI-enabled industrial computers requiring maximum I/O and expansion capacity.

Key Specifications

• Processor: Intel LGA1700 — 12th/13th Gen Core i3/i5/i7/i9, Xeon W (65W or 125W)
• Memory: 4× DDR5 4800MHz DIMM slots, up to 128GB
• Expansion: 2× PCIe 5.0 ×16, 1× PCIe 4.0 ×16, 2× PCIe 3.0 ×1
• Storage: 2× M.2 NVMe (PCIe 4.0 ×4), 8× SATA 6Gbps with RAID 0/1/5/10
• Display: HDMI 2.1, 2× DisplayPort 1.4, LVDS/eDP (up to 4 simultaneous)
• Networking: Dual Intel GbE LAN
• Serial I/O: 8× COM (RS-232/422/485)
• USB: 4× USB 3.2 Gen2, 6× USB 2.0
• Power: ATX 24-pin; 8-pin EPS; wide 12–24V DC option

Industrial Reliability Features

• Operating temperature: 0°C to 60°C
• Hardware watchdog timer (0.4 seconds to 254 minutes)
• TPM 2.0 on-board for Secure Boot and BitLocker
• 16-bit GPIO for hardware I/O control
• BIOS Write Protect switch
• IEC 60068-2 vibration and shock tested

The EMO-Q670 is available from TSL Automation Solutions — contact us for pricing, availability, and technical support for your SCADA server or workstation design.
